| Rahmen |
| Rahmen |
HEPHA 6061 Alloy Premium |
| Laufradgröße |
27,5'' |
| E-Bike System |
| Motor |
HEPHA P101C (100Nm / 250W / 25km/h) |
| Batterie |
HEPHA BT-100B (708Wh) |
| Display |
Hepha SC-201 1.96'' Display |
| Ladegerät |
HEPHA EC-P100B (6A / Ultra Fast) |
| Federung |
| Gabel |
Suntour SF19 NEX-E25-C NLO DS |
| Gabel Federweg |
63mm |
| Schaltung |
| Schaltung/Schaltwerk |
Shimano / Nexus / 5-Speed |
| Anzahl Gänge |
5 speed |
| Schalthebel |
Shimano / SL-C7000-5 / Nexus |
| Ritzel |
Gates / Sprocket Nexus / 28T |
| Kette |
Gates / CDX / BCD104, 42T, CL=45.5MM |
| Kettenblatt |
Gates / CDX / 122T |
| Kurbelgarnitur |
Alloy 165-ISIS, BLACK |
| Bremsen |
| Bremsen(v/h) |
Shimano BR-MT200 |
| Bremsscheiben(v/h) |
SM-RT54, M 180MMRT-EM300, M 160MM |
| Bremshebel |
Shimano BL-MT200 |
| Laufräder |
| Reifen |
Kenda / K1052 / 27.5" x 2.2" |
| Felgen |
Hepha Alloy / R25-1R / 27.5" / 584×25 |
| Speichen |
13G ED Black |
| Nabe(v/h) |
KT-TZ0FShimano / Nexus 5 |
| Steuerung & Sattel |
| Lenker |
Alloy 6061 / Width 660mm / Barbore: 31.8mm |
| Griffe |
DDK D2400-1 92mm / 130mm |
| Vorbau |
Satori UP2+ / Adjustable Stem / 90mm |
| Steuersatz |
H-856F5: OD56*ID39,8*CONE RACE_39,8 |
| Sattel |
Selle Royal Vivo 7823 BLACK COREL |
| Sattelstütze |
Alloy Seat Post, 31.6x300mm |
| Pedale |
Fuxon VPE-461 BORON AXLE, Alloy |
| Komponenten |
| Vorderlicht |
Litemove RX-E50 / 50 Lux |
| Rücklicht |
AXA Blue Line LED |
| Gepäckträger |
Standwell / Alloy / MIK HD ready |
| Schutzbleche |
SP-60C-27.5-Matte Black |
| Seitenständer |
Standwell-RA060JD, Alloy |
| Klingel |
Annuo, 11A-05 Bell black |
| Gewicht |
| Max. zul. Gesamtgewicht |
145 kg |
| Sonstiges |
| Anhängerfreigabe |
NEIN |
| STVZO konform |
Ja |
| Kategorie |
2 |
