Frameset
Rahmen
Orbea Gain Carbon OMR monocoque structure, Integrated Seat clamp with STVZO light, ICR cable routing, Thru Axle 12x142mm rear, thread M12x2 P1, Flat Mount disc, 700x35 max tyre, BB386 EVO, Mahle X20 AMC plug.
Gabel
Gain OMR carbon fork, 700x35 maximun tyre, Flat Mount disc, Thru Axle 12x100mm, thread M12x2 P1
Steuersatz
FSA 1-1/2" Integrated Aluminium Cup
Ebike
Akku
Mahle iX350 36V 353Wh
RANGE EXTENDER
N/A
Motor
Mahle motor hub X20, ALC
Display
Mahle Pulsar One monochrome ANT+ LEV
Ladegerät
Mahle Active Charger up to 4A
Remote
Mahle ONE Head Unit (BT/ANT+)
Remote2
Mahle Handlebar Dual eShifter
Übersetzung
Kurbel
Shimano 105 R7100 34x50t
hebel
Shimano Di2 R7170
Kassette
Shimano 105 R7100 11-34t 12-Speed
Schaltwerk
Shimano 105 Di2 R7150
Umwerfer
Shimano 105 Di2 R7150
Kette
Shimano M7100
Cockpit
Lenker
OC Road Performance RP21 Alu SL, Reach 80, Drop 125
Vorbau
OC Road Performance RP10, -8º
Bremsen
Bremsen
Shimano R7170 Hydraulic Disc
Laufräder
Laufradsatz
Alloy, Tubeless, 700c, 21c
Reifen
Pirelli P ZERO™ Race SmartEVO TLR 700x30c
Vorderradachse
Orbea Thru Axle 12x100mm M12x2 P1 Lite
Rear Hub
Orbea Thru Axle 12x142mm M12x2 P1 Lite
Komponenten
Sattelstütze
SP 0.2 Carbon, 27.2mm, Setback 20
Sattel
Fizik Aliante R5
Zubehör
Scheinwerfer
Rear position light, on saddle clamp, COB Led, On/Off, 12 Lumen. STVZO
Lenkerband
Orbea Anti-Slippery/Shock Proof
